48kWh to 96kWh 48V 1000Ah-2000Ah LiFePO4 Lithium Battery with Outdoor Cabinet

Brand: LINGRUI Delivery Date: 5-10 days Place of Origin: CHINA CHINA Transport To: Whole WorldFeature: LINGRUI 48V LBS series, with the advantages of small footprint, high energy density, long cycle life, safety and reliability, environmental protection, etc., it can be installed directly outdoor even without air conditioning
Contact sales
Model No
Rated Capacity
  • 1000Ah
  • 1200Ah
  • 1400Ah
  • 1600Ah
  • 1800Ah
  • 2000Ah
Energy Capacity
  • 48kWh
  • 57.6kWh
  • 67.2kWh
  • 76.8kWh
  • 86.4kWh
  • 96kWh
Battery Type
  • LiFePO4
Rated Voltage
  • 48V
Cycle Times
  • ≥7000 Cycles
Maintenance
  • Free Maintenance
Dimensions
  • 1200*800*1800mm
System Weight
  • 550KG
  • 650KG
  • 750KG
  • 850KG
  • 950KG
  • 1050KG
Waterproof Rating
  • IP65
Model No
Rated Capacity
  • 1000Ah
  • 1200Ah
  • 1400Ah
  • 1600Ah
  • 1800Ah
  • 2000Ah
Energy Capacity
  • 48kWh
  • 57.6kWh
  • 67.2kWh
  • 76.8kWh
  • 86.4kWh
  • 96kWh
Battery Type
  • LiFePO4
Rated Voltage
  • 48V
Cycle Times
  • ≥7000 Cycles
Maintenance
  • Free Maintenance
Dimensions
  • 1200*800*1800mm
System Weight
  • 550KG
  • 650KG
  • 750KG
  • 850KG
  • 950KG
  • 1050KG
Waterproof Rating
  • IP65
48V 1000Ah1000Ah48kWhLiFePO448V≥7000 CyclesFree Maintenance1200*800*1800mm550KGIP65
48V 1200Ah1200Ah57.6kWhLiFePO448V≥7000 CyclesFree Maintenance1200*800*1800mm650KGIP65
48V 1400Ah1400Ah67.2kWhLiFePO448V≥7000 CyclesFree Maintenance1200*800*1800mm750KGIP65
48V 1600Ah1600Ah76.8kWhLiFePO448V≥7000 CyclesFree Maintenance1200*800*1800mm850KGIP65
48V 1800Ah1800Ah86.4kWhLiFePO448V≥7000 CyclesFree Maintenance1200*800*1800mm950KGIP65
48V 2000Ah2000Ah96kWhLiFePO448V≥7000 CyclesFree Maintenance1200*800*1800mm1050KGIP65

Why choose
LINGRUI's 48V LBS series

Now, communication operators are using more environmentally friendly, more stable and longer service life lithium iron phosphate(LiFePO4) batteries to replace the previous lead-acid batteries.

LINGRUI's 48V LBS series has the advantages of small footprint, high energy density, long cycle life, safety and reliability, environmental protection.

Outdoor integrated base stations are easily affected by various external factors, such as temperature, humidity and windy weather,etc. In this harsh environment, LingRui 48V LBS series battery can effectively ensure the charging and discharging performance under high temperature. Even without air conditioning the 48V LBS series can operate normally. Avoiding the damage caused by high temperature.

LBS series Advantage

  • A communication base station can save more than 7,200 kWh of electricity each year
  • No heavy metals, environmental protection
  • Cycles times more than 7000 times, and the service life more than 10 years
  • Small size, small footprint, easy installation
  • High temperature resistance, can be directly installed outdoors, saving operating costs
  • Safe and reliable BMS system
  • Lifespan

    >10 Years

  • Parallel Connection

    Support

  • 80% DOD

    ≥7000 Cycle

  • Rated Capacity

    1000-2000Ah
