Array Storage Stacked LFP Battery LV/HV 15.36kwh 20.5kwh 25.6kwh 30.72kwh Solution

Brand: LINGRUI Delivery Date: 5-10 days Place of Origin: CHINA CHINA Transport To: Whole WorldFeature: Security Backup Protection.Stores energy,Help customer save money, Easy install and a minimalist design, The battery capacity can be increased freely and flexibly according to the situation of home use.
Contact sales
Model No
Nominal Voltage
  • 51.2V(16series)
  • 153.6V(48series)
  • 204.8V(64series)
  • 256V(80series)
  • 307.2V(96series)
Capacity
  • 300Ah
  • 400Ah
  • 500Ah
  • 600Ah
  • 100Ah
Energy
  • 15.36KWh
  • 20.48KWh
  • 25.6KWh
  • 30.72KWh
Design Life
  • ≥20 years
  • ≥10 years
Dimensions(mm)
  • 745*415*590
  • 930*415*590
  • 1120*415*590
  • 1300*415*590 mm
  • 745*415*590 mm
Weight
  • 195kg
  • 260kg
  • 310kg
  • 360kg
Cycle Life
  • ≥7000 cycles
Protocol(optional)
  • RS232-PC RS485(B)-PC
    RS485(A)-Inverter CANBUS-Inverter
Model No
Nominal Voltage
  • 51.2V(16series)
  • 153.6V(48series)
  • 204.8V(64series)
  • 256V(80series)
  • 307.2V(96series)
Capacity
  • 300Ah
  • 400Ah
  • 500Ah
  • 600Ah
  • 100Ah
Energy
  • 15.36KWh
  • 20.48KWh
  • 25.6KWh
  • 30.72KWh
Design Life
  • ≥20 years
  • ≥10 years
Dimensions(mm)
  • 745*415*590
  • 930*415*590
  • 1120*415*590
  • 1300*415*590 mm
  • 745*415*590 mm
Weight
  • 195kg
  • 260kg
  • 310kg
  • 360kg
Cycle Life
  • ≥7000 cycles
Protocol(optional)
  • RS232-PC RS485(B)-PC
    RS485(A)-Inverter CANBUS-Inverter
LSTK-15KW51.2V(16series)300Ah15.36KWh≥20 years745*415*590195kg≥7000 cyclesRS232-PC RS485(B)-PC
RS485(A)-Inverter CANBUS-Inverter
LSTK-20KW51.2V(16series)400Ah20.48KWh≥20 years930*415*590260kg≥7000 cyclesRS232-PC RS485(B)-PC
RS485(A)-Inverter CANBUS-Inverter
LSTK-25KW51.2V(16series)500Ah25.6KWh≥20 years1120*415*590310kg≥7000 cyclesRS232-PC RS485(B)-PC
RS485(A)-Inverter CANBUS-Inverter
LSTK-30KW51.2V(16series)600Ah30.72KWh≥20 years1300*415*590 mm360kg≥7000 cyclesRS232-PC RS485(B)-PC
RS485(A)-Inverter CANBUS-Inverter
LSTK-15KHV153.6V(48series)100Ah15.36KWh≥20 years745*415*590 mm195kg≥7000 cyclesRS232-PC RS485(B)-PC
RS485(A)-Inverter CANBUS-Inverter
LSTK-20KHV204.8V(64series)100Ah20.48KWh≥20 years930*415*590260kg≥7000 cyclesRS232-PC RS485(B)-PC
RS485(A)-Inverter CANBUS-Inverter
LSTK-25KHV256V(80series)100Ah25.6KWh≥20 years1120*415*590310kg≥7000 cyclesRS232-PC RS485(B)-PC
RS485(A)-Inverter CANBUS-Inverter
LSTK-30KHV307.2V(96series)100Ah30.72KWh≥10 years1300*415*590360kg≥7000 cyclesRS232-PC RS485(B)-PC
RS485(A)-Inverter CANBUS-Inverter

Product Features

  • The appearance is fashionable and beautiful, and it can be used as a craft ornament when placed indoors.
  • A variety of installation methods, which can be wall-mounted and stacked.
  • Hidden wiring method, the appearance is more tidy, avoiding the risk of subsequent electric shock.
  • It is equipped with universal wheels when stacking, which is convenient and labor-saving to place and move.
  • It can support 1-8 groups of batteries to be used in parallel (single battery 5KWH).


Product Introduction



Our Services

  • OEM and ODM service is acceptable.
  • All products will be tested 100% before shipment to ensure that the product does not have any quality problems.
  • We guarantee that warranty is 10 Years after delivery.
  • we accept sample order to test and check quality.
