Front Terminal Lithium LiFePO4

Brand: LINGRUI Delivery Date: 5-10 days Place of Origin: CHINA CHINA Transport To: Whole WorldFeature: Lighter weight & small size & easy to carry with BMS multiple protection keep battery safely Built-in automatic protection for over-charge and over discharge and over current and over temperature.
Contact sales
Model No
Rated Voltage
  • 12.8V
Rated Capacity
  • 50AH
  • 100AH
  • 120AH
  • 150AH
  • 200AH
Length
  • 275mm
  • 400mm
  • 555mm
Width
  • 105mm
  • 115mm
Height
  • 225mm
  • 290mm
  • 240mm
Weight
  • 6.5kg
  • 12kg
  • 13.5kg
  • 18kg
  • 24kg
Cycle Life
  • 5000 Cycles
Model No
Rated Voltage
  • 12.8V
Rated Capacity
  • 50AH
  • 100AH
  • 120AH
  • 150AH
  • 200AH
Length
  • 275mm
  • 400mm
  • 555mm
Width
  • 105mm
  • 115mm
Height
  • 225mm
  • 290mm
  • 240mm
Weight
  • 6.5kg
  • 12kg
  • 13.5kg
  • 18kg
  • 24kg
Cycle Life
  • 5000 Cycles
LFP12-5012.8V50AH275mm105mm225mm6.5kg5000 Cycles
LFP12-10012.8V100AH400mm115mm290mm12kg5000 Cycles
LFP12-12012.8V120AH555mm115mm240mm13.5kg5000 Cycles
LFP12-15012.8V150AH555mm115mm240mm18kg5000 Cycles
LFP12-20012.8V200AH555mm115mm240mm24kg5000 Cycles

Product Introduction

  • Using the technology of lifepo4 cell,superior safety,more than 5000 cycle times at100% DOD.
  • with BMS multiple protection easy installation and free maintenance.
  • The battery is highly use for telecom outdoor and communication base station and renewable energy systems and mountaion power generation and street light solar energy and RV power supply and other harsh environment applications.

Product Features

  • Lighter weight & small size & easy to carry
  • Built in Intelligent BMS Function.
  • with over charging & over discharging protect function.
  • Short-circuit protection function.
  • Temperature protection function.
  • Lighter weight about 40% ~50% of the weight of lead acid battery.
  • Wider work temperature range:-20℃~60℃
  • Support for Series application expansion (up to 51.2V) and 2 in parallel.
  • accept customized size and capacity and customied with LCD and bluetooth

Battery Application

  • Telecom outdoor applications
  • Communication base station
  • Street Light
  • Solar Energy
  • Renewable energy systems
  • Other harsh environment applications

Our Services

  • OEM and ODM service is acceptable.
  • All products will be tested 100% before shipment to ensure that the product does not have any quality problems.
  • We guarantee that warranty is 5 years after delivery.
  • we accept sample order to test and check quality.
