| Description | Specification | Notes |
| Battery pack specification |
| Cell type | LFP26650 lithium-ion cells |
|
| Combination mode | 32S12P |
|
| Rated voltage | 409 V |
|
| Voltage range of battery module | 256 V～460 V |
|
| Rated capacity | 38.4 Ah |
|
| Rated charging current | 1C |
|
| Rated discharge current | 1C |
|
| Operating humidity | 10%RH~90%RH |
|
| IP level | IP20 |
|
| Cooling | Natural cooling |
|
| Environmental characteristics |
| Temperature range of charging operation | 0~50℃ |
|
| Temperature range of discharge operation | -20~65℃ |
|
| Storage temperature and time | -20~25℃/12 months
-20~45℃/3 months
-20~60℃/1 month
|
|
| Safety certification and standard |
| Standard | IEC62619，UN38.3/a battery pack system |
|
| Mechanical structure |
| Dimension | 480(W)×600(D)×1000(H) |
|
| Weight | 200 kg |
|
